Air Pencil Grinder

WYMA Hot Sales Pneumatic Pencil Grinders, we price these competitively because they ship straight from our factory. We keep these ready to ship and back them with reliable service after your purchase. Get solid performance for your needs without breaking the bank. You'll find versatile models: 90°/120°Angle versions, 90°/120°Grinding Disc types, and the Straight style. We welcome ODM, OBM, and OEM projects, plus custom logos and body colors.

Equip with essential accessories like chuck(3mm/6mm), flint grinding head, emery grinding head, tungsten steel grinding head, flap disc head, grinding wheel head, cashmere grinding head, nylon fiber head, teel wire grinding head, cowhide grinding head, pipe brush, mini wrench for replacing chuck / grinding head, explosion-proof air hose, silencer air hose, oiler, bowl grinding wheel, self-adhesive sandpaper, multi-standard connectors( GB/BSP/NPT ) and pneumatic tool lubricants—select ideal attachments for your application.

All WYMA Air Pencil Grinders adhere to international standards, holding EU MD-CE certification for safety and reliability. Featured at key events: CIHF 2009 Tianjin, CIHF 2010-2011 Shanghai, CIHF 2011 Zhengzhou, AIFME 2012 Shunde, CISMEF 2015.10 Guangzhou Pazhou, and CIHF 2016 Shanghai.

Product’s Parameter (Specification)

Product’s Applications

Master intricate operations across industries with our WYMA Air Pencil Grinder. We built this spark-free pneumatic tool for high-speed grinding in tight spots where precision matters most, even under tough conditions like mold polishing, die grinding, and shaping complex contours. You can use it to efficiently clean up castings—remove gates, flash, and burrs from aluminum alloy, zinc, and other metals. It really shines in automotive shops too like deburring engine parts, smoothing out transmission welds, and putting a fine finish on metal surfaces. Do you need for ultra-fine processing? Our grinder can also tackles micro-hole grinding and finishing in aerospace and precision instrument shops.

But it’s not just for heavy industry. Artists and woodworkers use it for detailed grinding, jade or stone carving, ceramic tile sanding, and plastic shaping. You can also handle metal derusting, punching, and engraving bamboo or wood. We recommend it for delicate polishing, profiling edges, and etching artwork.

Our Pneumatic Pencil Grinder gets precise, safe results on metal, wood, plastic, and stone. When you choose WYMA, you will get a tool engineered to handle the intricate jobs that other tools easily can’t.

Product’s Feature and Details

Structural Upgrades & Grinding Precision

We engineered our WYMA Pneumatic Pencil Grinder for outstanding concentricity–amplitude errors stay within 0.01-0.03mm even at max speeds over 70,000 RPM. This gives you smooth, vibration-free operation where precision counts. Our upgrades actually boosted force output by 80%, how is this achieved? We added a fourth blade ( now 25% thicker at 1.0mm ), expanded the stainless-steel rotor by 12%, and used a hollow design to shave weight off the body. We also made the aerospace-grade alloy dual bearings 10% wider and enlarged the cylinder by 15% for better kinetic energy transfer. Coupled with a pure copper bearing seat ( rapid heat dissipation ) and housing with 6% larger diameter, this product ensures stability under heavy loads while maximizing material removal efficiency.

Premium Material Engineering for Longevity

We start with an SCM420 alloy steel cylinder for our grinders. How we process it matters– mature CNC-controlled heat treatment followed by precise quenching makes this cylinder outlaster than ordinary powder metallurgy versions. For critical wear parts, we added anti-corrosion upgrades: the cylinder bore gets a mirror polish to cut rotor friction down. Up front, you'll find ductile iron replacing aluminum in the housing and air intake, this switch means not easy to deform and air leak under high air pressure. Our blades now use high-density mesh fiber, this material keeps its strength even when lubricants runs low, plus it's lightweight and shatter-resistant–significantly extending service cycles in dust-heavy environments.

Intelligent Control & Operational Safety

Simplified handling defines WYMA Pneumatic Pencil Grinder: an integrated on-off switch / speed valve enables single-handed stepless adjustment ( forward = accelerate, reverse = decelerate ).  Safety is inherent : spark-free operation supports 10+ hours continuous runtime, while noise-dampening air hoses and explosion-proof air hose protect users. Component upgrades (e.g., ductile iron housing) eliminate breakage / slippage risks common with aluminum.

Rapid Replacing & Minimal Maintenance

Models WM-3330/WM-3321B include 6mm chucks for heavy engraving, while standard 3mm compatibility supports versatile grinding head swaps using included mini wrench.Change grinding heads in 3 steps:

① Wrench-loosen (do not remove) cap nut.

② For chuck replacement, fully unscrew cap.

③ Remove chuck (tap lightly if stuck).

Post-use care requires only 2-3 drops of pneumatic tools lubricants into the air intake before brief idling–no disassembly needed.This efficiency, combined with stainless steel/copper components resisting corrosion, ensures the Air Pencil Grinder remains reliable through extended industrial duty cycles.
